Using the Pick White Point and Pick Black Point Effects (Render Tools) in 2020 Fusion

You would use this function if your room has minimal lighting sources or you wanted to add depth to the render.



1. Open 2020 Fusion and load your design.

2. Go into View Perspective and select the Presentation, Presentation Plus, or *Publish Render to enable the Effects ribbon (Render Tools).
*Publish Render is applicable from version 7 onwards.

3. Select the Effects ribbon (Render Tools) tab.



4. Select Pick White Point and click on a point of white within your design.



5. Select Pick Black Point and click on a point of black within your design.



 2020 Fusion will prevent you from selecting anything that is too dark when using ‘Pick White’ and anything that is too light when using ‘Pick Black’.
